Overview

SIMATIC IPC547G

The SIMATIC IPC547G is a rugged industrial PC in 19" rack design (4U).

It offers:

  • Maximum performance

  • Attractive price

  • Intel Core i/Xeon technology, 6th generation



Benefits

Maximum system performance for complex automation and visualization tasks

  • State-of-the-art PC technology (e.g. Intel Core i processors 6th generation with Turbo Boost 2.0, hyper-threading and virtualization technology)

  • Memory and graphics controller integrated into processor for extraordinary memory and graphics performance

  • Maximum performance (e.g. Intel C236 chipset, DDR4 memory with the support of dual-channel technology)

  • High data transfer rates (e.g. with serial ATA solid-state drive up to 480 GB, serial ATA hard disks up to 2 TB, Dual Gigabit Ethernet, PCI Express 3.0 technology)

Reduction in downtimes through high system availability

  • 24-hour operation (high MTBF, variable-speed fan)

  • Efficient self-diagnostics (front status LEDs for fan and temperature, SIMATIC IPC DiagMonitor)

  • High degree of data security due to RAID1 (mirror disk system) or RAID5 (striping with parity), also with additional hot spare hard disk

  • "Hot swap" drive bays in RAID configuration (replacement of hard disk during operation)

  • Fast identification and replacement of the hard disk in the event of a fault by means of HDD alarm LEDs for RAID configurations

  • Solid-state drive option in conjunction with RAID1 (data in the RAID1 network on hard disks, preinstalled and activated operating system on solid-state drive)

  • Redundant power supply with "hot swap" functionality (replacement of power supply module during operation)

High flexibility and user friendliness during commissioning, operation and service

  • Preinstalled and activated operating system

  • IAMT (Intel Active Management Technology) functionality for remote access to the IPC (remote maintenance)

  • Fast restoration of the delivery status of the hard disk(s) thanks to restore DVD

  • Low noise output thanks to controlled fans

  • Universal implementation as an industrial workstation or server

  • RAID1/RAID5 onboard (a PCI slot is not occupied by the RAID Controller)

  • Flexible applications in many different positions with telescopic rails or as industrial tower PC

  • Intel Hybrid multi-monitor support for connecting up to 5 monitors in combination with optional PCIe x16 graphics card

  • High degree of flexibility and expandability thanks to integrated interfaces and 7 slots (P CI and PCI Express)

High industrial compatibility and compactness for 24-hour use in an industrial environment

  • Distinct product design with user-friendly enclosure concept

  • Maximum processor performance (in maximum configuration) without loss of power (throttling) at ambient temperatures of up to 40 °C

  • Metal enclosure with a high degree of electromagnetic compatibility and corrosion resistance for use in industrial areas as well as in domestic, business and commercial environments

  • Suitable for installing in space-saving control cabinets only 400 mm deep (short enclosure version)

  • Dust protection thanks to overpressure ventilation concept with fan on the front and dust filter

  • Special hard disk holders and card retainers for protection against vibration and shock

Cost reductions through high investment security

  • Availability of at least 2 years, guaranteed availability of spare parts for 3 years

  • System-tested with SIMATIC components

  • Certification for worldwide marketing (cULus)

  • Support for legacy interfaces (PS/2, COM, LPT)

  • Installation compatible spanning generations of devices

  • Worldwide service and support



Application

The SIMATIC IPC547G offers system integrators, cabinet designers, plant constructors and mechanical equipment manufacturers a 19" rack PC platform for high-performance applications and IT applications at the control and cell levels. It can be used for:

  • Process and visualization applications

  • Industrial high-end image processing

  • Quality assurance/monitoring tasks

  • Measuring and control tasks

  • Data acquisition/management

The SIMATIC IPC547G has the CE mark for use in the industrial sector as well as in residential and commercial areas. In addition to industrial applications, it can therefore also be used in building services automation or in facilities open to the public.

Ordering the SIMATIC Rack PCs in conjunction with WinCC flexible, WinCC RT Advanced, WinCC or WinAC RTX/F as SIMATIC HMI packages results in favorable prices





Design

Basic design

  • All-metal 19" enclosure for flush mounting (4 U) with corrosion-protected surface (blue chromate) and with optional design finish (paint finish 2)) for high electromagnetic compatibility and mechanical ruggedness

  • Two housing versions (short 356 mm deep and standard 446 mm deep) for enhanced flexibility

  • Prepared for mounting on telescopic rails

  • Horizontal and vertical installation is possible. It can be used as an industrial tower PC with the appropriate kit

  • Lockable front door for authorized access to front swap media, operator controls (power, reset), USB interfaces, front fan and dust filter

  • Card retainer for PC modules for safe transport (vibration and shock)

  • Replacement of PC components (e.g. PC cards or hard disks) with a single tool

  • Front fan and dust filter can be replaced without tools

  • Dust protection filter by means of overpressure ventilation with bearing seated front fan

  • Slots for installing drives (standard enclosure version):

    • Front:
      4 x low-profile HDD removable drive bay trays; 1 x ODD (slimline)

    • Internal:
      - 3 x 3.5"/2.5" in 5.25"; 2 x 3.5"/ 2.5" (optional)

  • Slots for installing drives (short enclosure version):

    • Internal: 2 x 3.5"/2.5"

Design versions

Mainboard (H110 chipset)

  • Onboard graphics: Intel HD graphics;

    • 530 / 510 integrated into processor

  • Interfaces

    • 2 x Intel Gigabit Ethernet (RJ45, teaming-capable)

    • 4 x USB 3.0: 2 x at the rear, 2 x at the front

    • 4 x USB 2.0: 4 x at the rear

    • 1 x DisplayPort V1.2, 1 x DVI-D, 2 x PS/2

    • Audio: Line in, line out, micro

  • 7 spare slots for expansions (all long 2)):

    • 1 x PCIe x16 Gen. 3

    • 1 x PCIe x16 (1 lane) Gen 2

    • 1 x PCIe x8 (1 lane) Gen 2

    • 1 x PCIe x4 (1 lane) Gen 2

    • 1 x PCIe x4 (1 lane) Gen 2

    • 2 x PCI

Mainboard (C236 chipset)

  • Onboard graphics: Intel HD graphics;

    • P530 / 530 / 510 integrated into processor

  • Interfaces

    • 2 x Intel Gigabit Ethernet (RJ45, teaming-capable)

    • 6 x USB 3.0: 4 x at the rear, 2 x at the front

    • 5 x USB 2.0: 4 x rear, 1 x internal e.g. for software dongle with optional interlocking

    • 2 x DisplayPort V1.2, 1 x DVI-D, 1 x COM1, 2 x PS/2

    • Audio: Line in, line out, micro

  • 7 spare slots for expansions (all long 2))

    • 1 x PCIe x16 Gen. 3

    • 1 x PCIe x16 (4 lanes) Gen 3

    • 1 x PCIe x8 (1 lane) Gen 3

    • 1 x PCIe x4 (4 lanes) Gen 3

    • 1 x PCIe x4 (1 lane) Gen 3

    • 2 x PCI



Main memory configuration

  • up to 64 GB, DDR4-2133 SDRAM

  • Available memory configurations: 4 GB, 8 GB, 16 GB, 32 GB, 64 GB 1)

Graphics expansion

  • PCI Express graphics card x16 (Dual Head: 2 x VGA or 2 x DVI-D), 1 TB, up to 2 048 x 1 536 pixels, 60 Hz, 32-bit colors

  • Adapter cable (DP to VGA) for the onboard graphics interface (1 x VGA) for connecting an analog monitor

Power supply

  • AC (100 ... 240 V, 50 ... 60 Hz)

  • Redundant: 2 x AC (100 ... 240 V, 50 ... 60 Hz 2))

  • Country-specific power cable

    • EU

    • USA

    • China
